Key Specifications

Imaging

Lens Mount

Canon EF

Lens Communication

Yes

Image Sensor

36 x 24 mm (Full-Frame) CMOS

Sensor Resolution

Not Specified by Manufacturer

Image Stabilization

No

Capture Type

Stills & Video

Exposure & Focus Control

Shutter Type

Electronic Rolling Shutter

ISO/Gain Sensitivity

Native: 100 to 25,600

Advertised Dynamic Range

13 Stops

Focus Modes

Automatic, Manual Focus

Video Capture

Internal Recording (Blackmagic RAW)

• 6048 x 4032 [75 to 555 MB/s]
• 4832 x 4032 [60 to 445 MB/s]
• 6048 x 3200 [60 to 441 MB/s]
• 4096 x 3072 [39 to 288 MB/s]
• 6048 x 2520 [47 to 348 MB/s]
• DCI 4K (4096 x 2160) [28 to 203 MB/s]
• 2112 x 1184 [9 to 59 MB/s]
• 1920 x 1080 [8 to 49 MB/s]

Video Output (SDI/BNC)

6048 x 4032, 6048 x 3200, 4096 x 3072, 6048 x 2520, 4096 x 2160, 1920 x 1080

Fast-/Slow-Motion Support

No

Built-In Microphone

Stereo

Interface

Media/Memory Card Slot

Dual Slot: CFexpress Type B

Video I/O

1x BNC (12G-SDI) Output

Audio I/O

• 1x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output
• 1x 1/8" / 3.5 mm TRS Stereo Input
• 1x Mini XLR Mic/Line Input (+48 V Phantom Power)

Power I/O

1x LEMO 2-Pin (12VDC) Input

Other I/O

2x USB-C, 1x BNC (Reference, Timecode), 1x RJ45 (10 Gigabit Ethernet)

Wireless

Bluetooth

Mobile App Compatible

No

Monitor & Power

Display Type

Fixed 4" Touchscreen LCD (1920 x 1080)

Battery Type

Sony BP-U Series

General & Environmental

Tripod Mount

5x 1/4"-20 Female (Bottom), 5x 3/8"-16 Female

Accessory Mounting Thread

2x 1/4"-20, 1x 3/8"-16, 4x M4 (on Camera Body)

Dimensions (W x H x D)

4.17 x 4.69 x 5.94" / 10.59 x 11.91 x 15.09 cm

Weight

3.3 lb / 1.5 kg (Body Only)

Operating Conditions

32 to 104°F / 0 to 40°C up to 90% Humidity

Storage Conditions

-4 to 113°F / -20 to 45°C

Packaging Info

Package Weight

5.23 lb

Box Dimensions (L x W x H)

10.8 x 7.7 x 6.9"
