Key Specifications

IP Video

H.264 / H.265:
1920 x 1080 Encoding

Video I/O

1x BNC (12G-SDI / 3G-SDI / 6G-SDI / HD-SDI) Input
1x BNC (12G-SDI / 3G-SDI / 6G-SDI / HD-SDI) Loop Output
1x BNC (12G-SDI / 3G-SDI / 6G-SDI / HD-SDI) Monitor Output
1x HDMI Monitor Output

Embedded Audio

SDI Input: 16-Channel
SDI Output: 16-Channel
HDMI Output: 2-Channel
LAN (RJ45) / USB Output

Power Consumption

25 W

Display

LCD

Transport Protocols

RTMP, SRT

Compatible Services

Facebook Live, Twitch, YouTube Live

Wireless

No

Wi-Fi

No

Bluetooth

No

Cellular Support

5G NR / 4G LTE via Unspecified SIM Type

Other I/O

1x RJ45 Fast Ethernet Input / Output
1x USB-C Output
1x USB-C Input / Output

Power I/O

1x IEC C14 Input
1x XLR 4-Pin Input

Operating Conditions

32 to 104°F / 0 to 40°C at 0 to 90% Humidity

Storage Conditions

-4 to 113°F / -20 to 45°C at 0 to 90% Humidity

Rackmount Size

1 U

Dimensions

6.9 x 5.5 x 1.75" / 17.5 x 14 x 4.45 cm

Weight

1.66 lb / 753 g
