Key Specifications

Lens Mount

B4

Image Sensor

23.1 x 12.99 mm (2/3"-Type) CMOS

Sensor Resolution

Not Specified by Manufacturer

Image Stabilization

No

ISO/Gain Sensitivity

Native: 400 to 3200 (100 to 25,600 Extended) | Gain: -6 to 18 dB

Internal Recording (Blackmagic RAW 10-Bit)

• 6144 x 3456 up to 50 fps
• 3840 x 2160 up to 59.94 fps
• 1920 x 1080 up to 150 fps

Internal Recording (ProRes 422 HQ/422)

• 3840 x 2160 up to 59.94 fps
• 1920 x 1080p up to 120 fps

Media/Memory Card Slot

• Dual Slot: SD/SDHC/SDXC (UHS-II)
• Dual Slot: CFast (CFast 2.0)

Video I/O

• 1x BNC (12G-SDI) Input
• 2x BNC (12G-SDI) Output

Mobile App Compatible

Yes: iPadOS Only

Battery

V-Mount

Imaging

Lens Mount

B4

Lens Communication

Yes

Image Sensor

23.1 x 12.99 mm (2/3"-Type) CMOS

Built-In ND Filter

Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters

Exposure Control

Advertised Dynamic Range

13 Stops

Video Capture

Internal Recording (Blackmagic RAW 10-Bit)

• 6144 x 3456 up to 50 fps
• 3840 x 2160 up to 59.94 fps
• 1920 x 1080 up to 150 fps

Internal Recording (H.265)

3840 x 2160 up to 59.94 fps

Internal Recording (ProRes 422 HQ/422)

• 3840 x 2160 up to 59.94 fps
• 1920 x 1080p up to 120 fps

Audio Recording

ProRes: 2-Channel, 24-Bit at 48 kHz

Interface

Media/Memory Card Slot

• Dual Slot: SD/SDHC/SDXC (UHS-II)
• Dual Slot: CFast (CFast 2.0)

Video I/O

• 1x BNC (12G-SDI) Input
• 2x BNC (12G-SDI) Output

Audio I/O

• 2x XLR 3-Pin Mic/Line Input (+48 V Phantom Power)
• 1x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Input/Output

Power I/O

• 1x XLR 4-Pin Input
• 1x XLR 4-Pin (12 to 20VDC) Output
• 1x Molex 12-Pin Input

Other I/O

• 1x USB-C (USB 3.2 / 3.1 Gen 2) (Shared with Video Output)
• 1x USB-C Data Input
• 1x BNC (Reference, Sync, Timecode) Data Input
• 1x Hirose 12-Pin (Camera Interface) Control Output

Wireless

Bluetooth

Mobile App Compatible

Yes: iPadOS Only (Blackmagic Camera Control App)

Monitor

Display Type

• Primary Monitor: Articulating 4" Touchscreen LCD
• Status Display: Fixed Non-Touchscreen LCD

Power

Power Consumption

100 W

General

Tripod Mount

3x 1/4"-20 Female (Bottom)

Accessory Mounting Thread

1x ARRI/Hirth Rosette

Netflix Approved

Yes

Dimensions (W x H x D)

10.95 x 9.93 x 5.9" / 27.81 x 25.22 x 15 cm

Weight

7.83 lb / 3.55 kg (Body Only)

Packaging Info

Package Weight

11.4 lb

Box Dimensions (L x W x H)

21 x 10.1 x 7.1"
