Key Specifications

Imaging & Sensor

Lens Mount

ARRI PL (Interchangeable, with Lens Communication)

Image Sensor

50.8 x 23.3 mm (Large Format) CMOS

Effective Resolution

140.8 Megapixel (17,520 x 8040)

Dynamic Range

16 Stops

Shutter Type

Electronic Rolling Shutter

Focus Mode

Automatic, Manual Focus

Video Recording & Output

Internal Recording (Blackmagic RAW 12-Bit)

17520 x 8040 up to 60.00 fps
16128 x 8040 | 15360 x 8040 | 14304 x 8040
12288 x 8040 | 9648 x 8040 | 17520 x 7296
12288 x 6912 | 12288 x 6480
11680 x 5360 up to 100 fps
10752 x 5360 | 8192 x 5360
12288 x 5112 up to 90 fps
8192 x 4608 | 8192 x 4320
8192 x 3408 up to 170 fps
5840 x 2680 | 4096 x 2680 | 4096 x 2304
4096 x 2160 | 4096 x 1704

Video Output

4096 x 2160 @ 23.98/24/25/29.97/30/50/59.94/60 fps
1920 x 1080p @ 23.98/24/25/29.97/30/50/59.94/60 fps
1920 x 1080i @ 50/59.94/60 fps

Interfaces & Connectivity

Video I/O

2x BNC (12G-SDI) Output
1x USB-C Viewfinder Output
2x USB-C Control/Data/Monitor

Audio I/O

2x XLR 3-Pin Mic/Line/AES/EBU (+48V Phantom Power)
1x 1/8" (3.5 mm) TRS Stereo Headphone Output
Built-In Stereo Microphone

Data / Network

1x RJ45 (10 Gigabit Ethernet)
Bluetooth (Android & iOS Compatible)

Other I/O

1x LEMO 8-Pin (Power Input)
1x LEMO 7-Pin | 1x Fischer 3-Pin
1x BNC (Reference, Timecode)

Physical & Monitoring

Primary Monitor

Articulating 5" Touchscreen OLED

Internal Storage

8 TB

Mounting

Bottom: 5x 3/8"-16, 4x 1/4"-20
Body: 3x 1/4"-20, 4x 3/8"-16

General

Netflix Approved: Yes
Battery: B-Mount
Weight: 8.72 lb / 3.96 kg (Body Only)
Dimensions: 10.15 x 6 x 6" / 25.78 x 15.2 x 15.2 cm

Packaging & Environmental

Operating Temperature

32 to 104°F / 0 to 40°C (up to 90% Humidity)

Packaging Details

Package Weight: 9.67 lb
Box Dimensions: 12.8 x 10.2 x 9.2"
