Key Specifications

Image Sensor

27.03 x 14.25 mm (Super35) CMOS

Sensor Resolution

Effective: 79.6 Megapixel (12,288 x 6480)

Image Stabilization

No

Internal Recording (Blackmagic RAW 12-Bit)

• 12288 x 6480 up to 60.00 fps
• 8192 x 4320 up to 120 fps
• 6144 x 3240 up to 120 fps
• 4096 x 2160 up to 240 fps
• *Also includes: 11520x6480, 7680x6408, 12288x5112 (up to 75 fps), 7680x4320, 5120x4272, 8192x3408 (up to 160 fps), 3840x2160, 2560x2136, 4096x1704 (up to 160 fps).

Video Output (Raw via USB)

• 12288 x 6480
• 8192 x 4320
• 6144 x 3240
• 4096 x 2160

Media/Memory Card Slot

• Dual Slot: SD/SDHC/SDXC (UHS-II)
• Dual Slot: CFast (CFast 2.0)

Video I/O

• 1x BNC (12G-SDI) Input
• 1x BNC (12G-SDI) Output
• 1x BNC (3G-SDI) Output

Mobile App Compatible

No

Imaging

Lens Mount

ARRI PL

Lens Communication

Yes

Image Sensor

27.03 x 14.25 mm (Super35) CMOS

Sensor Resolution

Effective: 79.6 Megapixel (12,288 x 6480)

Image Stabilization

No

Built-In ND Filter

Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters

Internal Filter Holder

No

Capture Type

Stills & Video

Exposure Control

Shutter Type

Electronic Rolling Shutter

Advertised Dynamic Range

14 Stops

Video Capture

Internal Recording (Blackmagic RAW 12-Bit)

• 12288 x 6480 up to 60.00 fps
• 8192 x 4320 up to 120 fps
• 6144 x 3240 up to 120 fps
• 4096 x 2160 up to 240 fps

Video Output (Raw via USB)

• 12288 x 6480
• 8192 x 4320
• 6144 x 3240
• 4096 x 2160

Fast-/Slow-Motion Support

Yes

Built-In Microphone

Stereo

IP Streaming

No

Interface

Media/Memory Card Slot

• Dual Slot: SD/SDHC/SDXC (UHS-II)
• Dual Slot: CFast (CFast 2.0)

Video I/O

• 1x BNC (12G-SDI) Input
• 1x BNC (12G-SDI) Output
• 1x BNC (3G-SDI) Output

Audio I/O

• 2x XLR 3-Pin Mic/Line Output (+48 V Phantom Power)
• 1x 1/8" / 3.5 mm TRRS Headphone/Mic Input/Output

Power I/O

• 1x XLR 4-Pin Input
• 1x Molex 12-Pin Input/Output
• 1x XLR 4-Pin (12VDC) Output

Other I/O

• 1x USB-C (USB 3.2 / 3.1 Gen 2)
• 1x USB-C Data Input

Mobile App Compatible

No

Global Positioning (GPS, GLONASS, etc.)

No

Viewfinder

Type

Optional, Not Included

General

Accessory Mounting Thread

• 4x 1/4"-20
• 1x ARRI/Hirth Rosette

Dimensions (W x H x D)

9.2 x 5.92 x 5.87" / 23.4 x 15.04 x 14.91 cm

Weight

5.62 lb / 2.55 kg

Packaging Info

Package Weight

8.25 lb

Box Dimensions (L x W x H)

14.9 x 8.8 x 8"
