Key Specifications

Lens Mount

Interchangeable Mount (PL Mount installed as per model name)

Image Sensor

27.03 x 14.25 mm (Super35) CMOS

Sensor Resolution

Effective: 79.6 Megapixel (12,288 x 6480)

Image Stabilization

No

ISO/Gain Sensitivity

Native: 125 to 3200

Internal Recording (Blackmagic RAW 12-Bit)

• 12288 x 6480 up to 60.00 fps
• 12288 x 5112 up to 75 fps
• 5120 x 4272 up to 160 fps
• 8192 x 3408 up to 160 fps
• 4096 x 2160 at 240 fps
• *Also records at resolutions including: 11520x6480, 7680x6408, 8192x4320, 7680x4320, 6144x3240, 3840x2160, 2560x2136, 4096x1704.

Video Output (Raw via USB)

• 12288 x 6480
• 8192 x 4320
• 6144 x 3240
• 4096 x 2160

Media/Memory Card Slot

• Dual Slot: SD/SDHC/SDXC (UHS-II)
• Dual Slot: CFast (CFast 2.0)

Video I/O

• 1x BNC (12G-SDI) Input
• 1x BNC (12G-SDI) Output
• 1x BNC (3G-SDI) Output

Mobile App Compatible

Yes: Android & iOS (via Bluetooth)

Battery

Built-In Lithium-Ion (plus external power options)

Imaging

Lens Mount

Interchangeable Mount (PL Mount installed)

Lens Communication

Yes

Image Sensor

27.03 x 14.25 mm (Super35) CMOS

Sensor Resolution

Effective: 79.6 Megapixel (12,288 x 6480)

Image Stabilization

No

Built-In ND Filter

Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters

Capture Type

Stills & Video

Exposure Control

Shutter Type

Electronic Rolling Shutter

ISO/Gain Sensitivity

Native: 125 to 3200

Advertised Dynamic Range

14 Stops

Focus

Focus Modes

Automatic, Manual Focus

Video Capture

Internal Recording (Blackmagic RAW 12-Bit)

• 12288 x 6480 up to 60.00 fps
• 12288 x 5112 up to 75 fps
• 5120 x 4272 up to 160 fps
• 8192 x 3408 up to 160 fps
• 4096 x 2160 at 240 fps

Video Output (Raw via USB)

• 12288 x 6480
• 8192 x 4320
• 6144 x 3240
• 4096 x 2160

Fast-/Slow-Motion Support

Yes

Built-In Microphone

Stereo

Audio Recording

2-Channel, 24-Bit at 48 kHz

Interface

Media/Memory Card Slot

• Dual Slot: SD/SDHC/SDXC (UHS-II)
• Dual Slot: CFast (CFast 2.0)

Internal Storage

No

Video I/O

• 1x BNC (12G-SDI) Input
• 1x BNC (12G-SDI) Output
• 1x BNC (3G-SDI) Output

Audio I/O

• 2x XLR 3-Pin Mic/Line Output (+48 V Phantom Power)
• 1x 1/8" / 3.5 mm TRRS Headphone/Mic Input/Output

Power I/O

• 1x XLR 4-Pin Input
• 1x Molex 12-Pin Input/Output
• 1x XLR 4-Pin (12VDC) Output

Other I/O

• 1x USB-C (USB 3.2 / 3.1 Gen 2)
• 1x USB-C Data Input

Wireless

Bluetooth

Mobile App Compatible

Yes: Android & iOS (Remote Control via Bluetooth)

Global Positioning (GPS, GLONASS, etc.)

No

Monitor

Display Type

• Primary Monitor: Articulating 4" Touchscreen LCD
• Status Display: Fixed Non-Touchscreen LCD

Viewfinder

Type

Optional, Not Included

Power

Battery

Built-In Lithium-Ion

Environmental

Operating Conditions

32 to 104°F / 0 to 40°C up to 90% Humidity

Storage Conditions

-4 to 113°F / -20 to 45°C

General

Accessory Mounting Thread

• 4x 1/4"-20
• 1x ARRI/Hirth Rosette

Netflix Approved

Yes

Dimensions (W x H x D)

9.2 x 5.92 x 5.87" / 23.4 x 15.04 x 14.91 cm

Weight

5.62 lb / 2.55 kg (Body Only)

Packaging Info

Package Weight

8.49 lb

Box Dimensions (L x W x H)

12.3 x 10.4 x 8.3"
