SHURE BLX24A/B58-K3E
SHURE BLX24A/B58-K3E
|
Key Specifications |
|
|
Wireless Technology |
Analog UHF |
|
Diversity |
Yes |
|
Max Operating Range |
300' / 91.4 m (Line of Sight) |
|
Receiver Type |
1x Tabletop/Rack-Mountable |
|
Number of Audio Channels |
1 |
|
Included Transmitters |
1x Handheld |
|
Microphone Type |
1x Handheld with Interchangeable Capsule (Beta 58A Included) |
|
System |
|
|
RF Frequency Band |
K3E: 606 to 630 MHz |
|
Max Transmitters per Band |
12 |
|
Dynamic Range |
100 dBA |
|
Receiver |
|
|
Mounting Options |
Rackmount (with Included Hardware, 1 U Half-Rack) |
|
Antenna |
2x Removable 1/4 Wave External (Rear-Mount) |
|
Audio I/O |
1x XLR 3-Pin Balanced Output |
|
Display |
Backlit LCD |
|
Transmitters |
|
|
RF Output Power |
10 mW |
|
Gain Range |
-20 to -10 dB |
|
Display |
Alphanumeric LED (In Battery Compartment) |
|
Microphones |
|
|
Polar Pattern |
Supercardioid |
|
Frequency Response |
50 Hz to 16 kHz |
|
Power |
|
|
Transmitter Battery Type |
2x AA (Included) |
|
Transmitter Battery Life |
14 Hours (Alkaline) |
|
Physical |
|
|
Housing |
ABS (Transmitter), Steel (Receiver) |
|
Dimensions |
Receiver: 7.8 x 6.4 x 2" |
|
Weight |
Receiver: 35.2 oz / 998 g |
|
Packaging Info |
|
|
Package Weight |
6.8 lb |
|
Box Dimensions (LxWxH) |
18.3 x 14.9 x 3.8" |
