Key Specifications

Microphone Type

Large Diaphragm

Polar Pattern

Cardioid

Element Type

Condenser

Sound Field

Mono

Diaphragm

1" / 25.4 mm

Orientation

End Address

Controls

Low Cut / HPF

Pad

No

Filter & EQ

Low-Cut Filter: 75 Hz

Circuitry

Solid-State (JFET)

Performance

Frequency Response

20 Hz to 20 kHz

Maximum SPL

128 dB (1 kHz, 1% THD, 1-Kilohm Load)

Sensitivity

-34 dBV/Pa (at 1 kHz)

Dynamic Range

114 dB (A-Weighted)

Equivalent Noise Level

14 dB SPL (A-Weighted)

Connectivity

Analog Output

1 × XLR 3-Pin Male

Power

Power Sources

Phantom Power

Operating Voltage

24 V / 48 V (Phantom Power)

Physical

Color

Stainless Steel

Dimensions

H: 2 × W: 2.6 × L: 6.6" / H: 50 × W: 65 × L: 167 mm

Weight

1.3 lb / 577 g

Packaging Information

Package Weight

2.015 lb

Box Dimensions (L × W × H)

10.7 × 5.3 × 2.4"
