Key Specifications

Frequency Response (-10 dB)

80 Hz - 20000 Hz

Max SPL @ 1m / 4m

101 dB / 89 dB

Coverage Angle

170°

System Sensitivity

88 dB (1W @ 4m: 76 dB)

Power Section

Power Handling

20 W (RMS), 80 W (Peak)

Constant Voltage Transformer

100 V

Power Selection (Taps)

20 W, 10 W, 5 W, 2.5 W

Transducers

Dome Tweeter

1 x 0.75"

Woofer

1 x 5.0" Coaxial

Standard Compliance

IP Protection Grade

IP 65

Safety Certifications

CE compliant, EN54-24 certified

CPR Number

0068-CPR-058/2014

Physical Specifications

Cabinet Material

Flameproof ABS, Steel grille

Hardware

Wall mount metal plate and 5m suspension cable

Color

White - RAL 9016

Dimensions (H x W x D)

261 x 176 x 183 mm / 10.28 x 6.93 x 7.2 inches

Weight

2.79 kg / 6.15 lbs

Shipping Information

Package Dimensions

230 x 350 x 230 mm / 9.06 x 13.78 x 9.06 inches

Package Weight

4.39 kg / 9.68 lbs
