Key Specifications

Product / Accessory Type

Portable Battery-Powered Acoustic Instrument / Multi-Purpose Amplifier

Acoustic & Electrical Performance Specifications

Amplifier Output Power

276 W Peak / Continuous Output (AC Power) / 236 W (Battery Power)

Amplifier Topology Class

Class-D Topology

Frequency Response

60 Hz to 20,000 Hz (20.00 kHz)

Speaker Component Specifications

Low/Mid-Frequency Transducers

1x 203.20 mm (8.00") Full-Range Speaker

High-Frequency Transducers (Tweeters)

2x 76.20 mm (3.00") Tweeters

Input & Output Impedance Specifications

Channel 1 Input Impedance

Hi-Z: 1 MΩ / Line: 10 kΩ

Channel 2 Input Impedance

Hi-Z: 1 MΩ

Auxiliary Input Impedance

AUX In: 20 kΩ

Smartphone Interface Impedance

Input: 20 kΩ / Output: 470 Ω

Line / Dual Link Interface Impedance

Line In / Dual In: 100 kΩ / Line Out / Dual Out: 200 Ω

Direct Output (DI Out) Impedance

DI Out: 300 Ω

Power & Battery Specifications

Internal Battery System

Built-in Rechargeable Lithium Battery (4,400 mAh Capacity)

Continuous Battery Runtime

Approximately 6 Hours

Dimensions & Weight Specifications

Product Dimensions (L×W×H)

462.00 mm x 261.00 mm x 272.00 mm (18.19" x 10.28" x 10.71")

Product Net Weight

9.40 kg (20.72 lbs)
