Key Specifications

General

• Speaker Type: Passive Column Array
• Configuration: 2-Way
• Total Passive Power Handling: 1000 W / 4000 W Peak (100 Hours), 1500 W / 6000 W Peak (2 Hours)
• Nominal Impedance: LF: 8 Ohms / HF: 4 Ohms
• Enclosure Type: Sealed

Drivers

• LF Driver: 6x 6.5" / 16.5 cm Woofer (Voice Coil: 2" / 50.8 mm, Magnet: Neodymium)
• HF Driver: 24x 1" / 25.4 mm Tweeter (Magnet: Neodymium)

Performance

• Frequency Range/Response: 45 Hz to 20 kHz (-10 dB)
• Maximum SPL: 137 dB (Peak), 134 dB (Continuous)
• Speaker Sensitivity: 102 dB

Signal Processing

• EQ & Filters: No

Physical

• Color: Black
• Mounting: 14 x M8 Bracket Point, 4 x Fly Point - Unspecified Thread (Top), 4 x Fly Point - Unspecified Thread (Bottom)
• Handles: No
• Construction Material: ABS, Fiberglass
• Environmental Resistance: No
• Dimensions: 40.2 x 9.8 x 13.6" / 1020 x 250 x 345 mm
• Weight: 85 lb / 38.6 kg

Packaging Info

• Package Weight: 82.3 lb
• Box Dimensions (L x W x H): 49.5 x 19 x 15"
