Key Specifications

Speaker

• Speaker Type: Passive Column Array
• Configuration: Full-Range Array
• Total Passive Power Handling: 800 (100 Hours), 1300 (2 Hours)
• Constant Voltage / Transformer Taps: 70 V: 15 / 30 / 60 / 120 W or 8 Ohms Bypass; 100 V: 30 / 60 / 120 W or 8 Ohms Bypass
• Nominal Impedance: 8 Ohms
• Enclosure Type: Sealed

Drivers

• Full-Range Driver: 16x 2" / 5 cm Cone (Magnet: Neodymium)

Performance

• Frequency Range/Response: 80 Hz to 20 kHz (-10 dB)
• Maximum SPL: 121 dB (Continuous), 127 dB (Peak)
• Speaker Sensitivity: 96 dB
• Coverage Angle: 150° H x 15° V, 150° H x 40° V

Signal Processing

• EQ & Filters: No
• Dynamic Processing: No

Physical

• Color: White
• Mounting: 18 x M6 Integrated Rigging (Rear), 1 x Bracket Point
• Handles: No
• Construction Material: ABS, Aluminum Grille, Fiberglass
• Environmental Resistance: No
• Dimensions: 39.4 x 6 x 3.8" / 1000.8 x 152.4 x 96.5 mm
• Weight: 15.8 lb / 7.2 kg

Packaging Info

• Package Weight: 24 lb
• Box Dimensions (L x W x H): 13.9 x 8 x 7.9"
