Key Specifications

Frequency Range / Response

42 Hz to 150 Hz (-3 dB)

Enclosure Type

Bass-Reflex

Total Output Power

500 W RMS / 1000 W Program / 2000 W Peak

Amplifier Class

Class-D

Drivers

LF Driver

1 x 18" / 45.7 cm Woofer
Voice Coil: 4" / 10.2 cm

Performance

Frequency Range / Response

42 Hz to 150 Hz (-3 dB)

Protections

DC Fault
Overcurrent
Overvoltage
Thermal
Undervoltage

Signal Processing

EQ & Filters

No

Dynamic Processing

Compression, HF Limiter, Limiter

Alignment Delay

No

Digital Signal Processing

No

Connectivity

Audio I/O

XLR 3-Pin Line Input
XLR 3-Pin Output

Network I/O

No

USB I/O

No

Wireless

No

Mobile App Compatible

No

Power

AC Input Power

100 to 120 VAC, 50 / 60 Hz
220 to 240 VAC, 50 / 60 Hz

AC Power I/O

1 x powerCON Input
1 x powerCON Output

Physical

Color

Black

Mounting

Stand Mount
1 x M20-Threaded Pole Socket (Top)

Suspension Points

M10 Fly Point (Quantity Not Specified)

Handles

2 x Side

Construction Material

Metal Grille, Plywood

Environmental Resistance

No

Weight

105.8 lb / 48 kg

Packaging Info

Package Weight

118 lb

Box Dimensions (L x W x H)

30 x 29 x 27.25"
