Key Specifications

Lens Mount

L-Mount

Image Sensor

36 × 24 mm (Full-Frame) CMOS

Sensor Resolution

24.6 Megapixels (Effective)

Image Stabilization

No

ISO / Gain Sensitivity

Native: 400–3200 (Extended: 100–25,600)

Dynamic Range

13 Stops

Internal Recording

Blackmagic RAW 12-Bit
6048×4032 up to 36 fps
6048×3200 up to 48 fps
4096×3072 up to 50 fps
6048×2520 up to 60 fps
DCI 4K (4096×2160) up to 60 fps
1920×1080 up to 120 fps (H.264 8-bit 4:2:0)

Video Output

HDMI (1920×1080p)

Media/Memory Card Slot

1× CFexpress Type B

Mobile App Compatibility

Yes (iOS – Blackmagic Camera Control)

Battery

Sony L-Series

Imaging

Lens Communication

Yes (Autofocus Supported)

Internal Filter Holder

No

Capture Type

Stills & Video

Exposure & Focus

Shutter Type

Electronic Rolling Shutter

Focus Modes

Manual / Automatic

Audio

Built-In Microphone

Stereo

Audio Recording

2-Channel

Audio Inputs

2× Mini XLR Mic/Line (+48V Phantom Power)
1× 3.5 mm TRS Stereo Mic/Line Input

Audio Output

1× 3.5 mm TRS Headphone Output

Interface & Connectivity

Video I/O

1× HDMI Output

Power I/O

1× Proprietary 12–20VDC Input

USB-C

1× USB 3.2 / 3.1 Gen 1 (Video/Control I/O)

Wireless

Bluetooth

Network / GPS

No

Monitor & Viewfinder

Display

5" Tilting Touchscreen LCD

Display Resolution

1920×1080

Viewfinder

Optional (Not Included)

Power & Environmental

Power Consumption

30 W

Operating Conditions

32–104°F / 0–40°C, up to 90% Humidity

Storage Conditions

-4–113°F / -20–45°C

Construction

Material

Carbon Fiber Polycarbonate Composite

Dimensions (W × H × D)

7.08 × 4.8 × 3.7" / 17.98 × 12.2 × 9.4 cm

Weight

2.65 lb / 1.2 kg (Body Only)

Packaging Info

Package Weight

4.2 lb

Box Dimensions (L×W×H)

10.2 × 6.9 × 6.7"
