Key Specifications

Product Code

39681

System Configuration

Configuration

1-Way Bass Reflex

Low Frequency Driver

1 × 18" Woofer with 3" Voice Coil

Dispersion

Omnidirectional (H × V)

Amplifier

Built-in Amplifier (RMS)

1200 W RMS

Built-in Amplifier (Peak)

2400 W Peak

Audio Performance

Frequency Response

33 Hz – 120 Hz (-6 dB)

Maximum SPL

134 dB Continuous / 138 dB Peak (Half-Space)

Input Impedance

22 kΩ

Crossover Frequency

Preset Dependent

Power

AC Power Requirement

640 VA

Connectivity

Input Connector

XLR with Loop Output

Power Cord Length

5 m (16.4 ft)

Physical Specifications

Net Dimensions (W × H × D)

555 × 572 × 660 mm (21.8 × 22.5 × 25.6 in)

Net Weight

41.5 kg (91.5 lb)

Transport Dimensions (W × H × D)

800 × 790 × 600 mm (31.4 × 31.1 × 23.6 in)

Transport Weight

48.5 kg (107 lb)
