CLA 406.2A
CLA 406.2A
FBT
UNIT: PIECE/S
Product Code: SKU:FBT-CLA406.2-CHN-1406
Key Features
FBT CLA 406.2A
FBT CLA 406.2A
|
Key Specifications |
|
|
Product Code |
41801 |
|
System Configuration |
|
|
Configuration |
2-Way |
|
Low Frequency Driver |
4 × 6.5" Woofer with 1.5" Voice Coil |
|
High Frequency Driver |
1 × 1.4" Neodymium Driver with 2.5" Voice Coil |
|
Dispersion |
100° × 25° (H × V) |
|
Amplifier |
|
|
Built-in Amplifier (LF/HF RMS) |
600 W / 300 W RMS |
|
Built-in Amplifier (LF/HF Peak) |
1200 W / 600 W Peak |
|
Audio Performance |
|
|
Frequency Response |
65 Hz – 20 kHz (-6 dB) |
|
Maximum SPL |
133 dB |
|
Input Impedance |
22 kΩ |
|
Crossover Frequency |
1.2 kHz |
|
Power |
|
|
AC Power Requirement |
640 VA |
|
Connectivity |
|
|
Input Connector |
XLR with Loop Output |
|
Power Cord Length |
5 m (16.4 ft) |
|
Physical Specifications |
|
|
Net Dimensions (W × H × D) |
190 × 1140 × 290 mm (7.5 × 44.8 × 11.4 in) |
|
Net Weight |
28 kg (61.7 lb) |
|
Transport Dimensions (W × H × D) |
320 × 1265 × 445 mm (12.5 × 49.8 × 17.5 in) |
|
Transport Weight |
31.5 kg (69.4 lb) |
FBT CLA 406.2A Accessories
- No accessories available.
