Key Specifications

Frequency Response

120 Hz – 18 kHz

LF Drivers

6 × 4" (100mm) / 1" Voice Coil

HF Driver

1 × 1.4" Voice Coil

Rated Power (100V)

37.5W / 75W / 150W / OFF

Low Impedance Mode

6 Ω (300W)

Acoustic Performance

Sensitivity

96 dB (1W/1m)

Maximum SPL

119 dB (Cont.) / 125 dB (Peak)

Dispersion (H × V)

100° × 50°

Crossover Frequency

2.2 kHz (Passive)

Physical & Connectivity

Input Connector

M22-2P

Dimensions (W×H×D)

127 × 979 × 144 mm

Weight

12 kg / PC
