Key Specifications

Frequency Response (-10 dB)

45 Hz - 250 Hz

Max SPL @ 1m

109 dB

Coverage Angle

180° (Omnidirectional)

System Sensitivity

89 dB

Power Section

Power Handling

80 W RMS / 320 W PEAK

Nominal Impedance

8 Ω

Constant Voltage Transformer

70/100 V

Power Selection (Taps)

80 W, 40 W, 20 W, 10 W, 5 W

Recommended Amplifiers

DMA 504, DMA 162, DMA 82, DMA 162P

Transducers

Woofer

1 x 6.5'', 1.5'' v.c.

Standard Compliance

Safety Agency

CE compliant

Physical Specifications

Cabinet / Case Material

ABS with Steel backcan

Color

White - RAL 9003

Dimensions (Dia x D)

300 x 202 mm / 11.81 x 7.95 inches

Recessed Depth

193 mm / 7.6 inches

Cut Out Diameter

260 mm / 10.24 inches

Weight

4.5 kg / 9.92 lbs

Shipping Information

Package Height

280 mm / 11.02 inches

Package Width

362 mm / 14.25 inches

Package Depth

362 mm / 14.25 inches

Package Weight

6 kg / 13.23 lbs
