Key Specifications

Input Connectors

HDMI 1.3 Input & Loop

1 × HDMI 1.3 (IN & LOOP)

HDMI 1.3 Input

1 × HDMI 1.3

3G-SDI Input & Loop

1 × 3G-SDI (IN & LOOP)

Output Connectors

Ethernet Ports

4 × Gigabit Ethernet Ports

Maximum Loading Capacity

Up to 2.6 Million Pixels

Maximum Output Width

3840 Pixels

Maximum Output Height

3840 Pixels

Audio Features

Audio Input

Audio Input Accompanied with HDMI Input Source

Audio Output

Via Multifunction Card

Volume Control

Output Volume Adjustment Supported

Layer Management

Layers

2 Layers

Layer Size Adjustment

Supported

Layer Position Adjustment

Supported

Layer Priority Adjustment

Supported

Output Synchronization

Synchronization Source

Internal Input Source Can Be Used as Sync Source

Cascaded Synchronization

Ensures Output Images of All Cascaded Units Remain Synchronized

Video Processing Features

Image Processing Technology

SuperView III Image Quality Processing

Output Scaling

Stepless Output Scaling

One-Click Full Screen

Supported

Input Cropping

Free Input Cropping

Preset Storage

Easy Preset Saving and Loading

User-Defined Presets

Up to 10 Presets Supported

Backup Features

Device Backup

Supported

Ethernet Port Backup

Supported

Cascading

Maximum Cascaded Units

Up to 4 Units

Image Mosaic Support

Supported

Image Quality Management

Brightness Adjustment

Supported

Saturation Adjustment

Supported

Contrast Adjustment

Supported

Hue Adjustment

Supported

Pixel-Level Calibration

Brightness and Chroma Calibration Supported

Calibration Software

Compatible with NovaLCT and NovaStar Calibration Software

Calibration Benefits

Removes Color Discrepancies and Improves Brightness and Chroma Consistency for Better Image Quality

Control & Operation

Operation Modes

Control via NovaLCT Software or Front Panel Knob and Buttons
