Key Specifications

Total Channels

10 Channels

Mic Preamps

2 x Studio-Grade High-Headroom Preamps

Phantom Power

Yes (Studio Grade +48V)

Inputs

2 x XLR (Balanced), 10 x 6.3 mm Jack

Outputs

2 x Main Out, 2 x Control Room (6.3 mm Jack)

DSP Effects

56 FX Logic Acoustic Modelling (Reverbs, Delays, Modulation)

USB Interface

16-bit / 48 kHz (Plug and Play)

EQ Section

3-Band Musical EQ

Technical Performance

Frequency Response

20 Hz – 20 kHz (±1 dB)

Signal to Noise Ratio

>78 dB ±5 dB @ Max Gain

Auxiliary

FX Send, Headphone Out, Pan/Balance Control

Physical Specifications

Dimensions (H x W x D)

52.8 x 293.9 x 183.8 mm

Net Weight

1.37 kg
