Key Specifications

Product Type

Speakers

Enclosure Color

White

Enclosure Material

ABS plastic

Speaker System

Series

Control 10 Series

System Components

2 speakers

Speaker Type

Coaxial - 2-way - passive

Nominal Output Power

90 Watt

Frequency Response

58 - 20000 Hz

Nominal Impedance

8 Ohm

Max Output Level (Max SPL)

112 dB

Sensitivity

92 dB

Integrated Transformer

70.7V/100V or 8 Ohm operation

Coverage

90° conical

Recommended Placing

In-ceiling mounted

Detachable Grilles

Yes

Speaker System Details

Driver Details

• Speaker: woofer driver - 8" - polypropylene
• Speaker: tweeter driver - 1" - silk - Ferro-fluid cooled

Miscellaneous

Included Accessories

Speaker grille, paint shield, template, mounting kit

Compliant Standards

NFPA 70, UL 2043, RoHS, UL 94 V-0, UL 94-5VB, NFPA 90, UL 1876, UL 1480, S7232/UL, C-Tick N108, IEC 60849, EN 60849

Dimensions & Weight

Diameter

12.1 in

Depth

10.8 in

Cutout & Mounting Dimensions

Diameter

11.1 in

Packaging Info

Package Weight

38.5 lb

Box Dimensions (L x W x H)

29.8 x 15.9 x 15.4"
