Key Specifications

Compatibility

Compatible Devices

FreeSpace IZA 250-LZ and IZA 190-HZ Amplifiers
FreeSpace IZA 2120-LZ/HZ and ZA 2120-LZ/HZ Amplifiers
FreeSpace DXA 2120 Amplifier
PowerShare PS602 and PS604 Amplifiers
ControlSpace ESP-00 II, ESP-880, ESP-1240, ESP-4120, and ESP-1600 Engineered Sound Processors

Connectors

Type

2 x RJ-45, Allows for Daisy-Chaining, TIA/EIA 568B Wiring Standard

Settings

Channel Selection

8 DIP Switch Bank

Type

Controller Type

Passive Controller with Linear Potentiometer (0 Ohm to 10 Kilohms) and 2-Position Switch

Cable Requirements

Cable Type

Cat 5

Maximum Cable Length

2000' / 609 m for FreeSpace and PowerShare Amplifiers
500' / 152 m for ControlSpace Processors (Shielded Cable)
100' / 30 m for ControlSpace Processors (Unshielded Cable)

Physical

Electrical Box Size

1-Gang

Color

Black, White

Dimensions (W x H x D)

Face: 1.5 × 2.6 × 0.7" / 38 × 66 × 19 mm
Total: 1.5 × 4.1 × 1.4" / 38 × 105 × 36 mm

Packaging Info

Package Weight

0.35 lb

Box Dimensions (LxWxH)

6 × 5.1 × 2"
