BOSE ControlSpace EX-1280C
BOSE ControlSpace EX-1280C
|
Key Specifications |
|
|
ADC |
24-Bit |
|
DAC |
24-Bit |
|
Sample Rate |
48 kHz |
|
Analog Inputs |
|
|
Inputs |
12 x Block 6-Pin Balanced Mic/Line Input (Detachable) |
|
Analog Outputs |
|
|
Outputs |
8 x Block 6-Pin Balanced Line Output |
|
Digital Inputs |
|
|
USB Input |
1 x USB Micro-B Stereo Input |
|
Digital Outputs |
|
|
AmpLink Output |
1 x RJ45 Coaxial AmpLink Output |
|
Network Connectivity |
|
|
Dante |
2 x RJ45 Coaxial Dante Input/Output |
|
VoIP |
1 x RJ45 Coaxial VoIP Input/Output (2 Lines) |
|
PSTN |
1 x RJ11 Coaxial PSTN Input/Output (1 Line, Transmitter/Receiver) |
|
Other Connectors |
|
|
GPIO |
1 x Block 6-Pin GPIO Input/Output |
|
USB Host |
1 x USB-A (Host Connection) |
|
Audio Performance |
|
|
Maximum Input Level |
+24 dBu |
|
Maximum Output Level |
+24 dBu |
|
Dynamic Range |
>115 dBA |
|
Frequency Response |
20 Hz to 20 kHz (+0.3 / -0.1 dB) |
|
THD+N |
0.002% (A-Weighted, at +4 dBu) |
|
Dimensions |
|
|
Size (HxWxD) |
19 × 11.1 × 1.7" / 48.3 × 28.2 × 4.4 cm |
|
Weight |
7.3 lb / 3.6 kg |
|
Packaging Info |
|
|
Package Weight |
9.69 lb |
|
Box Dimensions (LxWxH) |
23.7 × 15.1 × 4" |
