Key Specifications

Signal Processor / CPU

32-Bit Fixed / Floating-Point DSP 456 MHz / ARM Cortex-A8 600 MHz

Maximum Calculation

3.6 GIPS / 2.7 GFLOPS

Delay

43 s

Acoustic Echo Cancelling (AEC)

Tail Length

480 ms

Noise Reduction

32 dB

Latency

50 ms

Channels

12

References

4

Audio Over IP

Dante

16 x 16, Primary/Secondary, Routable to AEC

Indicators & Controls

Display

256 x 64 OLED with Rotary Encoder

LED Status Indicators

Power/Status

Audio Signal Indication

On Display

General

PC Configuration Software

ControlSpace Designer Software Version 5.5 or Later

Network Control

Ethernet (RJ-45), 1 Gbps

Operating Temperature

Temperature

32 – 104°F / 0 – 40°C

Cooling System

Cooling

2 Variable-Speed Fans, Side Venting

Compliance

Safety

UL60065 (8th Edition), CAN/CSA-C22.2 No.60065 (8th Edition), IEC/EN60065 (8th Edition), UL62368-1 (2nd Edition), CAN/CSA C22.2 No.62368-1-14 (2nd Edition), IEC/EN 62368-1 (2nd Edition)

EMC

EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55035:2017, FCC Part 15B Class A, AS/NZS CISPR 32:2015, ICES-003 Class A, CISPR13

Power

Mains Voltage

85 – 264 VAC, 50/60 Hz

AC Power Consumption

35 W Typical at 104°F (40°C) Ambient

Mains Connector

IEC 60320-C14 (Inlet)

Power Dissipation

60 W (205 BTU, 52 kcal)

Dimensions

Size (HxWxD)

1.7 × 19 × 11.1" / 4.3 × 48.3 × 28.2 cm

Weight

5.3 lb / 2.4 kg
