Key Specifications

Total Network I/O Channels

64 x 64

Total Network I/O Streams

32 x 32

Dante Channels

8 x 8 included; licensable up to 32 x 32

Local Analog I/O Channels

8 flex

AEC Processors

8

VoIP Instances

2

Audio Recording / Playback

4-channel recording / 16-channel playback (expandable to 32 channels with optional license)

Q-SYS NM-T1 Capacity

3 (base capacity); 6 (with Capacity Scaling License)

Network Peripherals

Up to 32

Mic / Line Inputs

Phantom Power

+48 VDC, 10 mA per input max

A/D-D/A Converters

24-bit

Sample Rate

48 kHz

Control

RS-232

2 ports

GPIO

8 x 8

USB Inputs & Outputs

Channel Count

8 x 8

Bit Depth

16-bit

Sample Rate

48 kHz

USB Audio Device Hosting

Supports standard USB headset and speakerphone

Environmental

Power Consumption

40 W typical

Physical Properties

Dimensions (H x W x D)

43.6 x 220 x 286.6 mm (1.72 x 8.66 x 11.28 in)

Weight

1.8 kg (4.0 lb)

Battery Chemistry

Lithium Carbon Monofluoride (embedded, non-accessible)
