Key Specifications

System Type

• Model: Hollyland Mars 400S Pro (Enhanced) TX/RX Kit
• Technology: Long-Range Wireless Video Transmission
• Max Range: 3000' / 914.4 m (Line of Sight)
• Latency: 33 ms

Transmitter (TX) Specifications

I/O & Power

• Inputs: 1x HDMI 1.4b, 1x BNC (3G-SDI)
• Loop Out: 1x BNC (3G-SDI)
• Power: 1x L-Series (NP-F) Plate | 10 W Consumption
• Weight: 7.4 oz / 210 g

Receiver (RX) Specifications

I/O & Features

• Outputs: 2x HDMI 1.4b, 2x BNC (3G-SDI)
• Network: 1x RJ45 Ethernet (RTSP Streaming support)
• Display: Built-in OLED Status Display
• Power: 1x V-Mount Plate | 11 W Consumption
• Weight: 15.5 oz / 440 g

Wireless & Physical

Technical Details

• Frequency: 5.1 to 5.85 GHz (40 MHz Bandwidth)
• Resolution: Up to 1080p60 (HDMI/SDI)
• Antennas: 2x RP-SMA on each unit
• Mounting: 1/4"-20 Female (Bottom)
