Key Specifications

Mixer

• Max I/O Capacity: 12x Input / 6x Output
• Number of Analog Input Channels: 12
• Number of Mic Preamps: No
• Number of Analog Output Channels: 8
• Mix Routing: 1x Stereo Main LRC, 6x Mono Bus
• Groups: No
• Presets: No
• Display: 7" Touchscreen (Backlit)
• Faders & Level Adjustment: No

Signal Processing

• Input Polarity: Normal/Reverse
• Dynamic Processing: Compressor, Gate
• Solo/Mute: Solo, Mute per Input Channel, Bus, Master
• Built-In Effects: 2x Stereo Effect (Type Unspecified)
• Automatic Mic Mixing: Yes

Digital Audio

• Sample Rates: 96 kHz

Connectivity

• Analog Inputs: 5x XLR 3-Pin Balanced Mic/Line, 5x Combo XLR-1/4" Balanced/Unbalanced Mic/Line, 2x 1/4" TRS Balanced/Unbalanced Stereo Line
• Analog Outputs: 2x XLR 3-Pin Stereo Main, 6x 1/4" TRS Balanced/Unbalanced Mix, 1x 1/4" TRS Unbalanced Stereo Headphone
• Phantom Power: +48 V
• Digital I/O: 1x RJ45 (Network)
• MIDI I/O: No
• USB I/O: 1x USB-A (Audio Playback, Audio Streaming, External Memory, Service), 1x USB-B 2.0 (Host Connection)
• USB I/O Capacity: 16x Input / 18x Output
• Wireless: Bluetooth
• External Display I/O: No

Recording

• Max Multitrack Recording: 16 Tracks
• Media Support: SD

Compatibility

• OS Compatibility: Android/iOS

Power

• Input Power: 12 VDC at 4 A, 100 to 240 VAC, 50 / 60 Hz

Physical

• Rack Mountable: Yes
• Rackmount Size: 6 U (with Non-Included Hardware)
• Operating Conditions: 32 to 104°F / 0 to 40°C
• Dimensions: 11.4 x 9.5 x 3.5" / 29 x 24.2 x 8.8 cm
• Weight: 5.3 lb / 2.4 kg

Packaging Info

• Package Weight: 9.025 lb
• Box Dimensions (L x W x H): 14.5 x 12 x 7.7"
