CS-760

1 6

High intelligible: suited to voice alarm, public address announcement and BGM application by 2way system.
IP-66 certified: All weather durability, be it water or dust. Ideal for any fully outdoor amplification.
Special paint coat prevents color degradation, ensuring long-lasting exterior condition.
Rotary switch facilitates hassle-free impedance change.
Various mounting brackets available as accessories allowing flexibility of mounting the speaker on a platform, in the ceiling, on the wall or on a pole.

TOA

₱17,500.00 VAT INC.

₱17,500.00

UNIT: PIECE/S

Product Code: SKU:TOA-CS760-CHN-934

High intelligible: suited to voice alarm, public address announcement and BGM application by 2way system.
IP-66 certified: All weather durability, be it water or dust. Ideal for any fully outdoor amplification.
Special paint coat prevents color degradation, ensuring long-lasting exterior condition.
Rotary switch facilitates hassle-free impedance change.
Various mounting brackets available as accessories allowing flexibility of mounting the speaker on a platform, in the ceiling, on the wall or on a pole.

Authorized Dealer

Certified Quality Products

After-Sales Support

Secure Payments

Quantity

TOA CS-760

Key Specifications
Audio Performance
Rated Input	60 W
Sensitivity (1 W, 1 m)	100 dB
Maximum SPL	117 dB (60 W, 1 m)
Frequency Response	100 Hz - 20 kHz
Directivity Angle	Horizontal: 90° / Vertical: 80°
Speaker Components & Hardware
Low Frequency	16 cm (6”) Cone-type
High Frequency	2.5 cm (1”) Dome Tweeter
Crossover Frequency	2.5 kHz
Connection	Speaker Cord (Hot: Black / Com: White)
Impedance Tappings
100 V Line	170 Ω (60 W), 330 Ω (30 W), 670 Ω (15 W), 1.3 kΩ (7.5 W)
70 V Line	83 Ω (60 W), 170 Ω (30 W), 330 Ω (15 W), 670 Ω (7.5 W)
Physical & Environmental
IP Rating	IP66 (Dust-tight and High-pressure water jets)
Dimensions (W x H x D)	388 × 310 × 367 mm
Weight	7.4 kg (16.31 lb)
Materials	ABS Enclosure, Stainless Steel Bracket (Black/White)
