Key Specifications

Form Factor/Type

Tabletop (Rack-Mountable with Included Hardware)

Number of Amplifier Channels

1

Load Impedance/Voltage Support

4 / 8 Ohms, 100 / 70 V

Power Rating per Channel

1 × 300 W at 8/4 Ohms

Performance

Frequency Response

20 Hz to 20 kHz ±1 dB (8 Ohms)

SNR/Noise

> 97 dBA SNR

THD/Distortion

≤ 0.5% THD (Full Range, at Rated Power)

Crosstalk

< -70 dBA (1 kHz)

Signal Processing

DSP

Yes

Audio Delay

No

EQ & Filters

2-Band EQ

Dynamics

Compressor, Limiter

Connectivity

Analog Audio I/O

1× Block 3-Pin Balanced/Unbalanced Input
1× Stereo 2RCA Unbalanced Summed-Mono Input
1× Barrier Strip Output

Digital Audio I/O

No

Network I/O

No

USB I/O

No

Phantom Power

No

Wireless

No

Power

Input Power

100 to 240 VAC, 60 / 50 Hz

Physical

Display

Single-LED Indicators Only

Operating Conditions

32 to 95°F / 0 to 35°C up to 95% Humidity

Dimensions (W × D × H)

17 × 11 × 3.5" / 43 × 27 × 8.9 cm

Weight

13.1 lb / 5.9 kg

Packaging Info

Package Weight

15.7 lb

Box Dimensions (L×W×H)

21.6 × 14.5 × 6"
