Key Specifications

Amplifier

• Form Factor/Type: Rackmount
• Number of Channels: 8 Input / 2 Output
• Amplifier Power Rating: 4 Ohms / 8 Ohms: 40 W Peak per Channel (1 kHz, 0.5% THD), 5 W RMS per Channel
• Load Impedance / Voltage: 4 Ohms (Minimum), 70 V (120 Ohms Minimum), 100 V (240 Ohms Minimum)

Performance

• Frequency Response: Amplifier: 20 Hz to 20 kHz ±2 dB (Low-Z), 80 Hz to 15 kHz ±2 dB (70/100 V); Line Output: 20 Hz to 20 kHz ±1 dB
• Input Sensitivity: Mic: 3 mVrms; Line: 775 mVrms; RCA: 300 mVrms
• I/O Impedance: Mic Input: 400 Ohms; Line Input: 20 Kilohms (Balanced); RCA Input: 50 Kilohms
• Output Level: Line Output: 5 Vrms (10-Kilohm Load)
• Insertion Loss: 1 dB Maximum
• SNR: > 90 dB
• THD: < 0.5% (20 Hz to 20 kHz, Main Output), 0.05% (Line Output)
• Crosstalk: -70 dB (1 kHz)

Signal Processing

• EQ: 2-Band

Connectivity

• Audio I/O: 2x Block 5-Pin Balanced Line/Mic Input, 6x Block 3-Pin Balanced Line/Mic Input, 6x Stereo RCA 5-Pin Unbalanced Summed-Mono Input, 2x Block 3-Pin Balanced Aux Output
• Other I/O: 2x RJ45 Remote/Volume
• Phantom Power: 27 VDC

Power

• AC Input Power: 100 to 240 VAC, 50 / 60 Hz
• AC Power Connector: 1x IEC

Physical

• Rackmount Size: 1 U
• Operating Conditions: 32 to 95°F / 0 to 35°C up to 95% Humidity
• Storage Conditions: -4 to 185°F / -20 to 85°C
• Dimensions: 17.2 x 1.7 x 11.9" / 436.9 x 43.2 x 302.3 mm
• Weight: 10.6 lb / 4.8 kg

Packaging Info

• Package Weight: 15.2 lb
• Box Dimensions (L x W x H): 20.6 x 16.4 x 4.7"
