Key Specifications

Cartridge Type

Electret Condenser

Frequency Response

70–16000 Hz

Polar Pattern

Cardioid

Output Impedance

180 Ω

Sensitivity (at 1 kHz, open circuit voltage)

–33 dBV/Pa[1] (22 mV)

Maximum SPL (1 kHz at 1% THD)

120 dB SPL

Signal to Noise Ratio (referenced at 94 dB SPL)

67 dB

Dynamic Range

93 dB

Self Noise (equivalent SPL, A-weighted, typical)

27 dB SPL

Common Mode Rejection (10 Hz to 100 kHz)

>45 dB

Preamplifier Output Clipping Level (1% THD)

−7 dBV

Polarity

Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3

Power Requirements

11–52 V DC[4], 2.0 mA

Environmental Requirements

Operating Temperature Range: -18° C to 57° C (0° F to 135° F)
Relative Humidity: 0 to 95%
