Key Specifications

Power Ratings & Output Configuration

Form Factor / Type

Rackmount (1 U)

Number of Channels

4

Load Impedance Support

4 / 8 Ohms

Power Output (4 Ohms)

4x 250 W

Power Output (8 Ohms)

4x 170 W

Bridged Power (8 Ohms)

2x 500 W

Performance Specifications

Frequency Response

20 Hz to 20 kHz ±1 dB

SNR / Noise Floor

100 dB SNR

THD (1 kHz)

≤ 0.15%

THD (Full Range)

≤ 0.3%

Connectivity & Processing

Analog Audio Inputs

4x Block 3-Pin Input

Analog Audio Outputs

4x Barrier Strip Output

Signal Processing / DSP

None / No

Network / Wireless / USB

No

Electrical & Physical

Input Power

120 VAC, 60 / 50 Hz (1x IEC)

Power Consumption

200 W (at 1/8 Power)

Display

Single-LED Indicators Only

Dimensions

19 x 15.7 x 1.7" / 483 x 400 x 44 mm

Net Weight

14.5 lb / 6.6 kg

Package Weight / Box Size

16.91 lb / 24.1 x 20.2 x 2.9"
