Key Specifications

Type

Dante Expansion Card

Compatibility

CS-R10, DSP-R10, RPio622, CL5/3/1, QL5/1, PM5D, DSP5D, M7CL, LS9, DM2000, DM1000, 02R96, 01V96, 01V96i; RSio64-D; MRX7-D, MTX5-D, DME24N, DME64N; TX4n, TX5n, TX6n

Audio Channels

16 × 16

Sample Rates

44.1, 48, 88.2, 96 kHz

Sample Rate Pull-Up/Down

+4.1667%, +0.1%, -0.1%, -4.0%

Sample Bit-Depth

16, 24, or 32-bit PCM

Network

2 × Gigabit Ethernet RJ45 Connectors

Redundancy

Glitch-Free Dante Audio Redundancy Using Dual Ethernet Networks (Redundant Mode)

Daisy Chaining

Supports Daisy Chain of Multiple Dante-MY16-AUD2 Cards (Switched Mode)

HA Remote

Supports HA Remote Capable Yamaha Products

Expandable

Up to Four Cards in MY16-Compatible Slots for 64 × 64 Audio Channels

Power Source

Proprietary Interface

Package Weight

0.955 lb

Box Dimensions (L × W × H)

10.1 × 9 × 2.9"

Manufacturer Part Number

DANTE-MY16-AUD2
