Key Specifications

Power Output

50 Watts RMS

Woofer

10" HH AUDIO Professional Woofer

Channels

Two Channels
FET and Drive with Mix Options

Drive Features

Provides gritty drive while maintaining clarity

Preshape Switch

Provides a mid-frequency cut for a scooped sound
Enhances highs and lows

EQ

3-Band EQ

Tilt Function

TILT Function

Cabinet & Construction

Cabinet Material

Precision-crafted 15mm Plywood Cabinet

Cabinet Features

Optimal Strength
Reduced Weight
Resonant and Natural Tonal Character

Handle

Top Mounted Steel Reinforced Strap Handle

Exterior Finish

Hard Wearing Black Vinyl

Protection

Steel Corners for Enhanced Protection

Design

DIGBETH Styling

Front Baffle

Removable Front Baffle

Connectivity

AUX Input

3.5mm AUX In

Headphone Output

3.5mm Stereo Headphone Jack

FX Loop

Yes

FX Send

Doubles as Line Out

D.I. Output

Balanced Male XLR D.I. Output (Pre EQ)

Power Supply

Power Supply Type

Internal Universal Switched Mode Power Supply

Input Voltage

100-200V~ 50/60Hz

Connector

IEC C14 Inlet Connector

Dimensions & Weight

Item Dimensions

435mm x 401mm x 301mm (HWD)

Item Weight

10.9 Kg

Carton Dimensions

510mm x 525mm x 365mm (HWD)

Carton Weight

13.3 Kg
