PIONEER DJ DDJ-REV1
PIONEER DJ DDJ-REV1
|
Key Specifications |
|
|
Product |
Pioneer DJ DDJ-REV1/SXJ |
|
Configuration |
Dual-Deck |
|
Number of Channels |
2x Stereo |
|
Performance Controls |
Beat Sync, Cues, EQ, FX, High-Pass Filter, Low-Pass Filter, Pitch Control, Sampler, Scratch, Search, Slip Mode, Transport Controls, Vinyl Mode |
|
Built-In Effects |
No |
|
Stems Processing |
No |
|
USB |
1x USB-B |
|
Platter/Jog Wheel |
2x Touch-Sensitive |
|
Motorized Platters |
No |
|
Faders |
2x Channel Level |
|
Display |
No |
|
Sample Pads |
8x Assignable per Deck (Backlit) |
|
EQ |
2x Channel EQ: |
|
Audio Inputs |
1x 1/4" TS Mic Input |
|
Audio Outputs |
1x 1/8" / 3.5 mm TRS Headphone Output |
|
Wireless |
No |
|
Media Card Slots |
No |
|
Internal Drive Bays |
No |
|
Supported File Formats |
AAC, AIFF, ALAC, FLAC, MP3, WAV |
|
Frequency Response |
20 Hz to 20 kHz |
|
SNR |
USB: 103 dB |
|
THD |
USB: 0.005% |
|
Included Software |
Serato DJ Lite |
|
Compatible Software (Not Included) |
Serato DJ Pro |
|
OS Compatibility |
Windows 7 or Later / macOS 10.12 to 10.14 |
|
Processor Requirement |
Intel Core i3 |
|
RAM Requirements |
4 GB |
|
Storage Requirements |
5 GB |
|
Minimum Display Resolution |
1280 x 720 |
|
Required Hardware |
Available USB 2.0 Port |
|
Internet Connection |
Required for Registration, Software/Driver Download |
|
Power Requirements |
USB Bus Power |
|
Power Supply Output |
5 VDC at 500 mA |
|
Operating Conditions |
41 to 95°F / 5 to 35°C at 5 to 85% Humidity |
|
Dimensions (W × D × H) |
20.7 x 10.1 x 2.3" / 52.6 x 25.7 x 5.8 cm |
|
Weight |
4.6 lb / 2.1 kg |
|
Package Weight |
6.185 lb |
|
Box Dimensions (L × W × H) |
22.9 x 12.8 x 5.6" |
