Key Specifications

Inputs/Outputs

• System Connection: PCIe 2.0 x4
• Video Inputs: 4x BNC (3G-SDI) Female
• Audio Inputs: No
• Other I/O: 1x BNC Blackburst, Reference, Tri-Level Sync Input
• Simultaneous Multi-Input Support: Not Specified by Manufacturer

Format Support

• Input Video Format:
  • SDI (8/10/12-Bit 4:4:4/4:2:2 RGB, YUV)
    • 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
    • 1080PsF 23.98/24/25/29.97/30 fps
    • 1080i 50/59.94/60 fps
    • 720p 50/59.94/60 fps
    • 576i / 625 lines 50 fps
    • 480i / 525 lines 60 fps
• Input Audio Format: Analog: 48 kHz / 24-Bit
• Embedded Audio: SDI: 16-Channel

Standards

• Video Standard Compliance: SMPTE 259M/292M/296M/372M/425M, ITU -R BT.601/BT.656
• HDR Support: Not Specified by Manufacturer

Hardware

• OS Compatibility: Windows 8.1.10 or Later, macOS 10.14.15 or Later, Linux

Power

• Power Consumption: 10 W

Environmental

• Operating Temperature: 37 to 72°F / 5 to 40°C
• Storage Temperature: -4 to 113°F / -20 to 45°C
• Operating Humidity: 0 to 90%

General

• Certifications: C-Tick, CE, FCC
• Dimensions: 3.7" / 9.4 cm
• Weight: 5.64 oz / 160 g

Packaging Info

• Package Weight: 0.54 lb
• Box Dimensions: 5.65 x 5.55 x 1.2" (LxWxH)
