Key Specifications

Inputs / Outputs

System Connection

PCIe 2.0 x4

Video Outputs

1x BNC (6G-SDI) Female
1x HDMI (2.0a) Female

Audio Outputs

No

Format Support

Output Video Format

SDI (8/10-Bit 4:2:2 YUV)
DCI 4K at 23.98/24/25 fps
UHD 4K at 23.98/24/25/29.97/30 fps
DCI 2K at 23.98/24/25 fps
DCI 2KPsF at 23.98/24/25 fps

SDI (8/10/12-Bit 4:4:4 RGB)
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF at 23.98/24/25/29.97/30 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
576i / 625 lines
480i / 525 lines

HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0)
DCI 4K at 23.98/24/25 fps
UHD 4K at 23.98/24/25/29.97/30 fps
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF at 23.98/24/25/29.97/30 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
576i / 625 lines
480i / 525 lines

Embedded Audio

SDI: 16-Channel
HDMI: 8-Channel

Standards

Video Standard Compliance

SMPTE 259M/292M/296M/372M/425M/ST-2081
ITU-R BT.601/BT.656

HDR Support

:

Hardware

OS Compatibility

Windows 7 or Later
macOS 10.14 or Later
Linux

Power

Power Consumption

10 W

Environmental

Operating Temperature

32 to 104°F / 0 to 40°C

Storage Temperature

-4 to 113°F / -20 to 45°C

Operating Humidity

0 to 90%

General

Dimensions

4.7" / 11.94 cm

Weight

3.17 oz / 90 g

Packaging Info

Package Weight

0.37 lb

Box Dimensions (LxWxH)

5.45 x 5.35 x 1.1"
