Key Specifications

Inputs/Outputs

• System Connection: PCIe 2.0 x8
• Inputs/Outputs: 8x DIN (Mini-BNC) (3G-SDI) Male
• Other I/O: 1x DIN (Mini-BNC) Blackburst, Reference, Tri-Level Sync Input
• Simultaneous Multi-Input Support: Yes: 8 Simultaneous Inputs

Format Support

• Input Video Format:
  • SDI (8/10/12-Bit 4:4:4/4:2:2 RGB, YUV)
    • 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
    • 1080PsF at 23.98/24/25/29.97/30 fps
    • 1080i at 50/59.94/60 fps
    • 720p at 50/59.94/60 fps
    • 480i / 525 lines at 60 fps
    • 576i / 625 lines at 50 fps
• Input Audio Format: Analog: 48 kHz / 24-Bit
• Output Video Format:
  • SDI (8/10/12-Bit 4:4:4/4:2:2 RGB, YUV)
    • 1080p at 23.98/24/25/29.97/30/50/59.94 fps
    • 1080PsF at 23.98/24/25/29.97/30 fps
    • 1080i at 50/59.94/60 fps
    • 720p at 50/59.94/60 fps
    • 480i / 525 lines at 60 fps
    • 576i / 625 lines at 50 fps
• Embedded Audio: SDI: 16-Channel

Standards

• Video Standard Compliance: SMPTE 259M/292M/296M/372M/425M, ITU -R BT.601/BT.656
• HDR Support: Not Specified by Manufacturer

Hardware

• OS Compatibility: Windows 8.1.10 or Later, macOS 10.14.15 or Later, Linux

Power

• Power Consumption: 22 W

Environmental

• Operating Temperature: 37 to 72°F / 5 to 40°C
• Storage Temperature: -4 to 113°F / -20 to 45°C
• Operating Humidity: 0 to 90%

General

• Certifications: C-Tick, CE, FCC
• Dimensions: 6.3" / 16 cm
• Weight: 4.59 oz / 130 g

Packaging Info

• Package Weight: 0.56 lb
• Box Dimensions: 7 x 5.55 x 1.05" (LxWxH)
