Key Specifications

Inputs/Outputs

• System Connection: PCIe 1.0 x8
• Video Inputs: 4x HDMI (2.0b)
• Simultaneous Multi-Input Support: Not Specified by Manufacturer

Format Support

• Input Video Format:
  • HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV)
    • 576i / 625 lines at 50 fps
    • 480i / 525 lines 59.94 fps
    • 720p 50/59.94/60 fps
    • 1080p 23.98/24/25/29.97/30/50/59.94/60 fps
    • 1080i 50/59.94/60 fps
    • UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps
    • DCI 4K 23.98/24/25/29.97/30/50/59.94/60 fps
  • DVI
    • 480p at 60 fps

Standards

• HDCP Support: No
• HDR Support: Not Specified by Manufacturer

Hardware

• OS Compatibility: Windows 8.1 or Later, macOS 10.14 or Later, Linux

Power

• Power Consumption: 23 W

Environmental

• Operating Temperature: 41 to 104°F / 5 to 40°C
• Storage Temperature: -4 to 113°F / -20 to 45°C
• Operating Humidity: 0 to 90%

General

• Certifications: CE, FCC, RCM
• Dimensions: 4.29" / 108.97 mm
• Weight: 4.51 oz / 128 g

Packaging Info

• Package Weight: 0.4 lb
• Box Dimensions: 6 x 5.5 x 1" (LxWxH)
