Key Specifications

Inputs/Outputs

• Video I/O:
  • Input: 1x BNC (6G-SDI)
  • Output: 1x BNC (6G-SDI)
• Other I/O:
  • Input: 1x BNC (Reference)
  • Input: 1x DE-9/DB-9 (RS-422)

Format Support

• Video Resolution:
  • SDI Input (10-Bit 4:4:4/4:2:2)
    • 4096 x 2160 at 23.98/24/25 fps
    • 3840 x 2160 at 23.98/24/25/29.97/30 fps
    • 2048 x 1080 at 23.98/24/25 fps
    • 1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
    • 1920 x 1080PsF at 23.98/24/25/29.97/30 fps
    • 1920 x 1080i at 50/59.94/60 fps
    • 1280 x 720 at 50/59.94/60 fps
    • 720 x 576i at 50 fps
    • 720 x 480i at 59.94 fps
  • SDI Output (8-Bit 4:4:4/4:2:2)
    • 4096 x 2160 at 23.98/24/25 fps
    • 3840 x 2160 at 23.98/24/25/29.97/30 fps
    • 2048 x 1080p at 23.98/24/25 fps
    • 1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
    • 1920 x 1080PsF at 23.98/24/25/29.97/30 fps
    • 1920 x 1080i at 50/59.94/60 fps
    • 1280 x 720 at 50/59.94/60 fps
    • 720 x 576i at 50 fps
    • 720 x 480i at 59.94 fps
• Audio Format: Unspecified Digital Signal Input
• Embedded Audio: SDI: 16-Channel

Standards

• Video Standard Compliance: SMPTE: 259M/292M/296M/372M/425M/ST-2081, ITU-R: BT.601/BT.656
• HDCP Support: No
• Broadcast System Compatibility: NTSC, PAL

General

• Certifications: C-Tick, CE, FCC
• Dimensions: 3.75" / 9.53 cm
• Weight: 4.5 oz / 128 g

Packaging Info

• Package Weight: 0.45 lb
• Box Dimensions: 5.5 x 5.3 x 1.1" (LxWxH)
