Key Specifications

Active or Passive

Active

System Type

Subwoofer

Configuration

Bass-reflex

System Continuous Power

900 W

System Peak Power

1800 W

Max SPL @ 1m

130 dB (Half Space)

Freq Range (-10 dB)

35 Hz - 200 Hz

Freq Response (+/-3 dB)

42 Hz - 200 Hz

Bluetooth

No

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

15"

LF Voice Coil Size

4"

LF Rated Impedance

8 Ω

Preset Library

No

Input Connector

TRS Jack and Socket XLR

Enclosure Material

Birch Plywood

Grille Material and Finish

Steel Black

Finish

Black Tough-Tone

Handles

2

Deployment

Ground

Pole Mount

35 mm

Brackets Included

No

Rigging

No

Sensitivity 2.83v / 1m

n/a dB

System Rated Impedance

n/a

Crossover Frequency

80 Hz - 200 Hz (Adjustable)

Recommended HPF = BW 18 dB/OCT.

35 Hz

Transformer (T)

No

Amplifier Design

Class D

EQ Type

None

Active Loudspeaker Input Impedance

Balanced: 20K Ω / Unbalanced: 10K Ω

Link Connector

2 × Pin XLR

Input Sensitivity

Line: 0 dBu

Max Input Level

22 dBu

Line Output

Pin XLR

Main Power

AC100-120 V~ / 220-240 V~, 50/60 Hz

Power Supply

High Efficiency SMPS

Included Accessory

User Manual, AC Cable

Unpacked - Height (mm)

471

Unpacked - Width Front (mm)

471

Unpacked - Width Rear (mm)

471

Unpacked - Depth (mm)

600

Packed - Height (mm)

556

Packed - Width Front (mm)

672

Packed - Width Rear (mm)

672

Packed - Depth (mm)

543

Weight - Nett (kg)

33.1

Weight - Gross (kg)

36.7
