Key Specifications

Active or Passive

Active

System Type

Full-Range

Configuration

2-way

System Continuous Power

800 W

System Peak Power

1600 W

Max SPL @ 1m

131.5 dB

Freq Range (-10 dB)

45 Hz - 20 KHz

Freq Response (+/-3 dB)

50 Hz - 20 KHz

Bi-amp Mode Switch

No

Bluetooth

No

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

15"

LF Voice Coil Size

3"

LF Rated Impedance

8 Ω

HF Driver Type

Compression Driver

HF Voice Coil Size

2"

HF Diaphragm Material

Titanium

HF Exit Size

1"

HF Power (RE:AES2-2012)

50 W

HF Rated Impedance

8 Ω

HF Nominal Coverage (H x V)

90° x 45°

Preset Library

No

Input Connector

1/4” Jack / XLR Combo / 2 × RCA

Waveguide Type

Elliptical

Enclosure Material

Birch Plywood

Grille Material and Finish

Steel Black

Finish

Black Tough-Tone

Handles

2

Deployment

Flying, Ground, Pole

Pole Mount

Dual Angle (0° / 10°) 35 mm

Brackets Included

No

Rigging

Yes

M10

6

Sensitivity 2.83v / 1m

n/a dB

System Rated Impedance

n/a

Crossover Frequency

2.0 kHz

Recommended HPF = BW 18 dB/OCT.

45 Hz

Transformer (T)

No

Amplifier Design

Class D

EQ Type

None

Active Loudspeaker Input Impedance

Balanced: 20K Ω / Unbalanced: 10K Ω

Link Connector

Pin XLR

Input Sensitivity

Mic: -40 dBu / Line: 0 dBu

Max Input Level

22 dBu

Line Output

Switchable LOOP/MIX Balanced Pin XLR

Main Power

AC100-120 V~ / 220-240 V~, 50/60 Hz

Power Supply

High Efficiency SMPS

Included Accessory

Quick Start Guide, AC Cable

Unpacked - Height (mm)

700

Unpacked - Width Front (mm)

446

Unpacked - Width Rear (mm)

281.4

Unpacked - Depth (mm)

406

Packed - Height (mm)

803

Packed - Width Front (mm)

638

Packed - Width Rear (mm)

366

Packed - Depth (mm)

498

Weight - Nett (kg)

30.5

Weight - Gross (kg)

35.4
