Key Specifications

Active or Passive

Passive

System Type

Full-Range

Configuration

2-way

System Continuous Power

400 W

System Programme Power

800 W

System Peak Power

1600 W

Max SPL @ 1m

129 dB

Freq Range (-10 dB)

55 Hz - 20 kHz

Freq Response (+/-3 dB)

60 Hz - 20 kHz

Bi-amp Mode Switch

No

Bluetooth

No

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

12"

LF Voice Coil Size

3"

LF Rated Impedance

8 Ω

LF Power (RE:AES2-2012)

400 W

HF Driver Type

Compression Driver

HF Voice Coil Size

2"

HF Diaphragm Material

Titanium

HF Exit Size

1.4"

HF Power (RE:AES2-2012)

50 W

HF Rated Impedance

8 Ω

HF Nominal Coverage (H x V)

90° x 45°

Preset Library

Yes

Input Connector

2 × 4 Pole Speaker Connector

Waveguide Type

Elliptical

Enclosure Material

Birch Plywood

Grille Material and Finish

Steel Black

Finish

Black Tough-Tone

Handles

2

Deployment

Ground, Flying, Pole

Pole Mount

Dual Angle (0° / 10°) 35 mm

Brackets Included

No

Rigging

Yes

M10

6

Sensitivity 2.83v / 1m

97 dB

System Rated Impedance

8 Ω

Crossover Frequency

1.8 kHz

Recommended HPF = BW 18 dB/OCT.

55 Hz

Transformer (T)

No

EQ Type

None

Included Accessory

User Manual

Unpacked - Height (mm)

630

Unpacked - Width Front (mm)

390

Unpacked - Width Rear (mm)

241

Unpacked - Depth (mm)

373

Packed - Height (mm)

773

Packed - Width Front (mm)

566

Packed - Width Rear (mm)

566

Packed - Depth (mm)

464

Weight - Nett (kg)

24.7

Weight - Gross (kg)

29
