Key Specifications

Active or Passive

Passive

System Type

Full-Range

Configuration

Quasi 3-way

System Continuous Power

1000 W

System Programme Power

2000 W

System Peak Power

4000 W

Max SPL @ 1m

137 dB

Freq Range (-10 dB)

40 Hz - 20 kHz

Freq Response (+/-3 dB)

45 Hz - 20 kHz

Bi-amp Mode Switch

No

Bluetooth

No

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

2 × 15"

LF Voice Coil Size

3"

LF Rated Impedance

8 Ω

LF Power (RE:AES2-2012)

2 × 500 W

HF Driver Type

Compression Driver

HF Voice Coil Size

2"

HF Diaphragm Material

Titanium

HF Exit Size

1.4"

HF Power (RE:AES2-2012)

50 W

HF Rated Impedance

8 Ω

HF Nominal Coverage (H x V)

90° x 45°

Preset Library

Yes

Input Connector

2 × 4 Pole Speaker Connector

Waveguide Type

Elliptical

Enclosure Material

Birch Plywood

Grille Material and Finish

Steel Black

Finish

Black Tough-Tone

Handles

3

Deployment

Ground

Pole Mount

None

Brackets Included

No

Rigging

No

Sensitivity 2.83v / 1m

101 dB

System Rated Impedance

4 Ω

Crossover Frequency

1.8 kHz

Recommended HPF = BW 18 dB/OCT.

40 Hz

Transformer (T)

No

EQ Type

None

Included Accessory

User Manual, 2 × Castor Wheels

Unpacked - Height (mm)

1135

Unpacked - Width Front (mm)

488

Unpacked - Width Rear (mm)

300

Unpacked - Depth (mm)

450

Packed - Height (mm)

1218

Packed - Width Front (mm)

558

Packed - Width Rear (mm)

558

Packed - Depth (mm)

522

Weight - Nett (kg)

52.9

Weight - Gross (kg)

59
