DesignMax DM10P-SUB

1 4

BOSE

₱40,500.00 VAT INC.

~~₱45,000.00~~ ₱40,500.00

UNIT: EACH

Product Code: SKU:BOSE-DESIGNMDM10PSB-CHN-167

Authorized Dealer

Certified Quality Products

After-Sales Support

Secure Payments

Quantity

BOSE DesignMax DM10P-SUB

Key Specifications
Active/Passive	Passive
Number of Included Speakers	1
Speaker Configuration	Subwoofer
Power Handling	300 W RMS 1200 W Peak
Constant Voltage / Transformer Taps	70 V: 20 / 40 / 80 / 150 W or 8 Ohms Bypass 100 V: 40 / 80 / 150 W or 8 Ohms Bypass
Impedance	8 Ohms
LF Driver	1x 10" / 25.4 cm Woofer
Frequency Range	40 Hz to 125 Hz (-10 dB)
Color	Black
Speaker
Active/Passive	Passive
Number of Included Speakers	1
Speaker Configuration	Subwoofer
Power Handling	300 W RMS 1200 W Peak
Constant Voltage / Transformer Taps	70 V: 20 / 40 / 80 / 150 W or 8 Ohms Bypass 100 V: 40 / 80 / 150 W or 8 Ohms Bypass
Impedance	8 Ohms
Drivers
LF Driver	1x 10" / 25.4 cm Woofer
Performance
Frequency Range	40 Hz to 125 Hz (-10 dB)
Frequency Response	46 Hz to 108 Hz (-3 dB)
Maximum SPL	116 dB (Peak)
Sensitivity	85 dB
Recommended High-Pass Filter	45 Hz, 24 dB/Octave
Connectivity
Inputs/Outputs	1x Block 6-Pin Speaker Input/Thru
Maximum Wire Gauge	14 AWG / 2.5 mm
Physical
Environmental Resistance	No
Color	Black, White
Mounting	Suspension (Top)
Construction Material	Perforated Metal Grille, Plastic
Dimensions	15.7 x 15.1" / 39.9 x 38.4 cm
Weight	19.7 lb / 8.9 kg
Packaging Info
Package Weight	30.69 lb
Box Dimensions (LxWxH)	22.5 x 21.7 x 20.2"
