Key Specifications

Acoustic Components & Drivers

Speaker Configuration

2-way Full-Range (Passive)

LF Driver

1x 5.25" (133 mm) Woofer

HF Driver

1x 1" (25 mm) Neodymium Dome Tweeter

Enclosure Type

Sealed (Backcan)

Performance Data

Frequency Range (-10 dB)

65 Hz – 20 kHz

Frequency Response (-3 dB)

73 Hz – 17 kHz

Sensitivity (SPL / 1W @ 1m)

87 dB

Maximum Peak SPL

105 dB

Nominal Coverage Angle

135° Conical

Electrical & Power Handling

Power Handling (RMS / Peak)

60 W / 240 W

Program Power Handling

120 W

Nominal Impedance

8 Ohms (Bypass mode)

70V Transformer Taps

3, 6, 12, 25, 50 W

100V Transformer Taps

6, 12, 25, 50 W

Physical & Connectivity

Input Connectors

Euroblock 6-Pin (Input/Thru)

Maximum Wire Gauge

14 AWG (2.5 mm)

Construction Material

Plastic with Stainless Steel Grille

Color / Environmental

White / Indoor Only (No resistance)

Dimensions (Diameter x Depth)

11.9" x 8.1" (302 x 206 mm)

Weight (Each)

9.6 lb (4.4 kg)

Quantity

Pair (2 Speakers included)
