BOSE DesignMax DM5SE
BOSE DesignMax DM5SE
|
Key Specifications |
|
|
Acoustic Components & Performance |
|
|
Power Configuration |
2-way (Passive / Non-powered) |
|
LF Driver Size |
5.25" Woofer |
|
HF Driver Size |
1" Neodymium Driver |
|
Frequency Range (-10dB) |
65Hz – 20kHz |
|
Crossover Frequency |
1800 Hz (24dB/octave) |
|
Maximum Peak SPL |
104dB SPL |
|
Coverage Angle (H x V) |
135° x 135° |
|
Electrical Data |
|
|
Total Power Handling |
50W |
|
Transformer Taps (70V) |
50W, 25W, 12W, 5W, 3W |
|
Transformer Taps (100V) |
50W, 25W, 12W, 3W |
|
Nominal Impedance |
8 ohms |
|
Input Connector |
Euroblock 6-pin |
|
Physical & Installation |
|
|
Enclosure Material |
Engineered Plastic with Aluminum Grille |
|
Environmental Rating |
Indoor and Outdoor application |
|
Mounting Hardware |
U-bracket included (Wall-mount) |
|
Dimensions (H x W x D) |
11.2" x 7.5" x 8.4" |
|
Weight (per unit) |
9.7 lbs. |
|
Quantity |
Sold as Pair |
|
MPN |
829705-0220 |
