Key Specifications

Active/Passive

Passive

Number of Included Speakers

2

Speaker Configuration

Subwoofer

Power Handling

180 W
720 W Peak

Constant Voltage / Transformer Taps

70 V: 20 / 40 / 80 / 150 W
100 V: 40 / 80 / 150 W

Impedance

8 Ohms (Transformer Bypassed)

Full-Range Driver

1x 8" / 203.2 mm

Frequency Range

38 Hz to 155 Hz (-10 dB)

Frequency Response

45 Hz to 117 Hz (-3 dB)

Maximum SPL

112 dB
118 dB (Peak)

Sensitivity

89 dB

Inputs/Outputs

Block 6-Pin

Maximum Wire Gauge

14 AWG / 2.5 mm

Certifications

UL-1480A, S559, CE

Environmental Resistance

No

Operating Temperature

32 to 122°F / 0 to 50°C

Color

Black, White

Mounting

In-Ceiling

Dimensions

16.1 x 10" / 408.9 x 254 mm

Weight

21.9 lb / 9.9 kg (Each Speaker, with Grille)
