Key Specifications

Acoustic Components & Drivers

Speaker Configuration

2-Way Full-Range (Passive)

LF Driver

1x 8" (203 mm) Woofer

HF Driver

1x 1" (25 mm) Center-exit Compression Driver

Enclosure Type

Sealed (Backcan)

Performance Data

Frequency Range (-10 dB)

52 Hz – 20 kHz

Frequency Response (-3 dB)

60 Hz – 20 kHz

Sensitivity (SPL / 1W @ 1m)

93 dB

Maximum Peak SPL

121 dB

Nominal Coverage Angle

130° Conical

Electrical & Power Handling

Power Handling (RMS / Peak)

150 W / 600 W

Program Power Handling

300 W

Nominal Impedance

8 Ohms (Bypass mode)

70V Transformer Taps

2.5, 5, 10, 20, 40, 80 W

100V Transformer Taps

5, 10, 20, 40, 80 W

Physical & Connectivity

Input Connectors

Euroblock 6-Pin (Input/Thru)

Maximum Wire Gauge

14 AWG (2.5 mm)

Construction Material

Plastic with Stainless Steel Grille

Color / Environmental

White / Indoor Only (No resistance)

Dimensions (Diameter x Depth)

15.6" x 10" x 9.8" (396 x 254 x 249 mm)

Weight (Each)

22.8 lb (10.3 kg)

Quantity

Pair (2 Speakers included)
