Key Specifications

Network Interfaces

Interfaces

16 x 1000Base-T, Auto MDI/MDIX

Switching Capacity

32 Gbps

Maximum Forwarding Rate

23.808 Mpps

MAC Address Table Size

8000 Entries

Packet Buffer Size

256 KB

Jumbo Frame Support

Up to 9,216 Bytes

Performance & Control

Flow Control

IEEE 802.3x Flow Control

HOL Blocking Prevention

Yes

Power Saving

By Link Status and Cable Length

Energy Efficient Ethernet (EEE)

Yes

Power

Power Input

100 to 240 VAC

Maximum Power Consumption

9.3 W

Standby Power Consumption

4.48 W

Maximum Heat Dissipation

33.554 BTU/h

Physical

Dimensions (W × D × H)

282.2 x 178 x 44.5 mm (11.11 x 7.01 x 1.75")

Weight

1.06 kg

Cooling

Fanless

Acoustic Noise

0 dB

Environmental

Operating Temperature

0 to 40°C

Storage Temperature

-40 to 70°C

Operating Humidity

10% to 90% RH

Storage Humidity

5% to 95% RH

Reliability & Compliance

MTBF

208,124 Hours

RoHS 6 Compliant

Yes
